Electrical wires often face wear, tear, and exposure to harsh weather at their installation sites—and the National Electrical Code (NEC) outlines clear protective solutions to address these risks. Conduit systems have emerged as a durable choice for safeguarding wiring in industrial and commercial settings, offering reliable defense against environmental hazards and physical damage. But what exactly is a conduit system? What types of electrical conduit are available, and how do you choose the right one for your project? Let’s dive in.

What Is an Electrical Conduit System?

Since electricity became a staple in industrial and residential settings, the National Fire Protection Association (NFPA) has provided guidelines for safe equipment and installation practices. Bare wires pose significant safety risks, so rigid and flexible tubing was developed to shield electrical wiring. During World War II, naval and aerospace electrical applications demanded lightweight, flexible protection for wiring—and manufacturers rose to the challenge, producing liquid-tight and shielding conduit at scale to meet military needs.

In the post-war era, the first liquid-tight flexible metallic conduit was approved for commercial use, paving the way for modern conduit systems. Today, a wide range of rigid and flexible tubing options exist for wiring protection, but the core purpose remains the same: to shield wires from harm. Liquid-tight fittings were later engineered to complement these conduits, creating a complete, end-to-end protective solution.

At its core, a conduit system consists of liquid-tight conduit paired with liquid-tight fittings, working together to seal out water, dust, and debris from electrical wiring.

Common Types of Conduit Systems

There are three primary categories of conduit systems widely used in commercial and industrial applications:

• Liquid-tight flexible metallic conduit (LFMC) with compatible fittings
• Liquid-tight flexible non-metallic conduit (LFNC) with compatible fittings
• Food-grade liquid-tight flexible metallic conduit with specialized fittings

These conduit systems are typically listed by Underwriters’ Laboratories (UL) and approved by the Canadian Standards Association (CSA), ensuring they meet rigorous safety and performance standards. All compatible fittings also carry these certifications, providing peace of mind for installers and inspectors alike.

Key Standards for Conduit Compatibility & Performance

Conduit and fittings are designed to adhere to universal standards, ensuring interchangeability and reliability:

• Consistent trade sizes allow conduit and fittings to fit seamlessly with junction boxes and knockout holes.
• Threaded fasteners compress seals to create long-lasting, leak-proof connections for wiring runs.
• Fasteners can be tightened to UL and CSA torque requirements, guaranteeing secure installations.
• Threaded connections are easily removable, enabling inspection, maintenance, or upgrades to wiring systems.

Installation Support for Conduit Systems

Many manufacturers and industry resources offer instructional videos to simplify conduit cutting and fitting installation, including guides for:

• Liquid-tight flexible metallic conduit (LFMC) and fitting assembly
• Type A liquid-tight flexible non-metallic conduit (LFNC) installation
• Food-grade liquid-tight flexible metallic conduit and fitting setup
• MIL-PRF-24758A(SH) compliant shielded conduit and AISI 316 stainless steel fitting assembly

The Benefits of Using Electrical Conduit Systems

Investing in a high-quality conduit system delivers multiple advantages for commercial and industrial projects:

1. Superior Protection

Well-designed liquid-tight conduit and fittings provide consistent, reliable protection for wiring. Top-tier systems meet the highest NEC protection standards for flexible conduit, making them suitable for Class I Division 2 Hazardous Locations—some of the most demanding environments for electrical safety. Whether shielding against moisture, dust, physical impact, or chemical exposure, conduit systems are engineered to safeguard wiring in diverse conditions worldwide.

2. Organized, Adaptable Wiring

Conduit systems offer practical benefits for wiring management:

• Conduit is available in a range of colors that comply with UL and CSA safety requirements, making it easy to identify different wiring types.
• Larger trade sizes accommodate future wiring upgrades, eliminating the need for full system overhauls.
• Threaded fittings allow junctions to be opened for routine inspection and maintenance.
• Compact fitting options—including 45-degree elbows, 90-degree elbows, and straight configurations—support versatile routing.
• Elbow fittings feature swept bores (smooth internal curves) that simplify wire pulling, reducing friction and damage during installation.

3. Flexibility for Diverse Applications

Conduit systems are engineered to adapt to a wide range of installation scenarios:

• UL-listed liquid-tight conduit with straight fittings is approved for direct burial and concrete encasement, enabling seamless transitions from exposed runs to underground trenches.
• A generous bend radius allows conduit to navigate around obstacles or withstand soil movement, crushing forces, and water intrusion when buried.
• Halogen-free fittings paired with zero-halogen UL-listed conduit are safe for confined spaces, where toxic halogen gas emissions must be avoided.
• UL-listed conduit can be installed under raised floors, making it ideal for data centers and server rooms. Color-coded options (such as blue for computer wiring) help distinguish IT-related runs.
• Extreme-temperature-rated conduit (UL-listed and CSA-approved) performs reliably in harsh hot or cold environments.
• Elbow fittings (45-degree and 90-degree) provide built-in strain relief when connecting to junction boxes. For outdoor or wet locations, conduit and wiring can be configured with a drip loop to prevent liquid from entering the box.

4. Compliance with Safety Standards

Industrial and commercial projects require strict adherence to safety regulations, and conduit systems are designed to meet these demands:

• U.S. and Canadian building codes mandate the use of approved conduit and fittings—and reputable systems undergo rigorous testing to meet these standards.
• Food and pharmaceutical facilities require conduit that can withstand frequent washdowns and decontamination. Food-grade conduit systems (compliant with NSF and FDA requirements) are specifically engineered for these environments, including non-contact and splash-rated applications.

Tips for Selecting & Installing Electrical Conduit Systems

To ensure a safe, effective installation, keep these key tips in mind:

1. Choose the Right Trade Size

Select a conduit size that matches your wiring needs:

• Align the conduit and fitting size with the diameter of the wire or cable bundle, as well as the knockout holes in junction boxes.
• Follow NEC fill volume guidelines (refer to NFPA 70 2023 NEC Chapter 9, Table 1, based on the number of conducting wires) to avoid overcrowding—wires should not occupy more than 30% of the conduit’s internal volume. This ensures easier bending, wire pulling, and future maintenance.
• Reserve extra space in conduit used for direct burial or trench installations to prevent delays during wire pulling.

2. Select Conduit for Frequent Bending

If your project involves wiring that will be bent regularly (e.g., machinery or sensor wiring in factories), opt for flexible non-metallic conduit designed for frequent flexing. These types of conduit offer excellent impact resistance and recovery, standing up to repeated bending without compromising protection.

3. Ensure Secure, Sealed Connections

• Clean and dry all conduit ends and fittings before assembly to ensure a tight seal.
• Tighten threaded fittings to the torque requirements specified by UL and CSA. This step is critical for achieving a liquid-tight and dust-tight connection.

4. Verify Compliance with Local Regulations

• Choose conduit and fittings that are UL-listed and CSA-approved—these certifications give safety inspectors confidence in the installation’s integrity.
• For food and pharmaceutical facilities, confirm that food-grade conduit carries the NSF certification mark, as inspectors will verify this compliance during audits.

Final Thoughts

Electrical conduit systems are a cornerstone of safe, reliable wiring in commercial and industrial settings, offering protection, organization, and flexibility. By understanding the different types of conduit systems, their benefits, and best practices for selection and installation, you can ensure your electrical project meets code requirements, withstands environmental challenges, and supports long-term performance. Whether you’re wiring a data center, a manufacturing plant, or a food processing facility, the right conduit system is an investment in safety and durability.

‍
