When you're planning or installing an electrical conduit system, conduit bodies are the unsung heroes that make bends smoother, wire pulls easier, and future maintenance accessible. Whether you're tackling a residential wiring project, setting up a commercial electrical system, or working on an industrial facility, knowing your way around conduit body types—like LB, LL, LR, C, T, and TB—can save you time, reduce headaches, and ensure your work meets the relevant electrical safety standards.​

In this guide, we'll break down everything you need to know about conduit bodies, from the basics of the popular LB style to industry-specific applications and pro tips for choosing the right one.​

What Exactly Is an LB Conduit Body?​

Let's start with the most common type: the LB conduit body. Shaped to create a 90-degree turn, it features an access cover on its back—this is what makes it a go-to for electricians. The design lets you pull wires through the bend or splice them without disassembling the entire conduit run. It's especially handy in tight spaces, like cramped utility closets or wall cavities, where later adjustments to wiring might be necessary. If you've ever wondered how electricians navigate wires around corners without chaos, the LB conduit body is likely the solution.​

Conduit Bodies by Material: Which One Fits Your Project?​

Conduit bodies come in a range of materials, each tailored to specific environments and needs. Here's how to choose:​

1. Aluminum Conduit Bodies​

• Pros: Lightweight (easy to handle and install) and naturally corrosion-resistant.​

• Best For: Outdoor projects (like exterior lighting) or industrial settings. It pairs well with rigid metal conduit or galvanized steel conduit.​

• Why It Works: Aluminum stands up to rain, humidity, and mild chemicals without rusting, making it a durable, cost-effective choice for exposed areas.​

2. Malleable Iron Conduit Bodies​

• Pros: Heavy-duty, ultra-durable, and built to withstand impact and extreme conditions.​

• Best For: Harsh or hazardous environments—think factories with heavy machinery, or areas where durability is non-negotiable.​

• Why It Works: Malleable iron resists dents, scratches, and temperature fluctuations, making it ideal for high-stress industrial applications.​

3. PVC Conduit Bodies​

• Pros: Non-metallic (so no risk of electrical conductivity), easy to cut and assemble, and highly resistant to water and chemicals.​

• Best For: Wet, underground, or corrosive environments—like outdoor sprinkler systems, underground telecom lines, or poolside wiring. It's designed to work with Schedule 40 or Schedule 80 PVC conduit.​

• Why It Works: PVC doesn't rust, rot, or corrode, and it's affordable enough for large-scale underground projects.​

4. Stainless Steel Conduit Bodies​

• Pros: Maximum corrosion resistance (even against saltwater and harsh chemicals) and a clean, sanitary finish.​

• Best For: Marine applications (boat docks, coastal buildings), food-grade facilities (restaurants, bakeries), or chemical plants.​

• Why It Works: Stainless steel resists rust from saltwater and maintains hygiene standards in food processing—critical for industries where cleanliness is regulated.​

Common Trade Sizes: Get the Right Fit​

Conduit bodies are measured in "trade sizes," ranging from ½ inch to 4 inches. Smaller sizes (½–1 inch) are typical for residential or light commercial projects (like wiring outlets or light fixtures), while larger sizes (2–4 inches) are used in high-capacity industrial settings (such as power distribution for factories).​

A key rule: Always match the conduit body size to your conduit type (e.g., a 1-inch LB body for 1-inch conduit) and check that it meets the relevant wire fill requirements—overpacking wires can cause overheating and safety issues.

Pro Tips for Choosing the Right Conduit Body​

1. Match Material to Environment First​

• Wet areas = PVC or stainless steel​

• Corrosive spaces (chemicals, saltwater) = stainless steel​

• Industrial/high-impact = malleable iron​

• Indoor/light use = aluminum​

2. Pick the Style for Access and Direction​

• Need a 90° turn? Go LB, LL, or LR (depending on access side).​

• Splitting wires? T or TB.​

• Straight runs with maintenance needs? C.​

3. Check Certifications​

Always choose conduit bodies with recognized safety certifications—this guarantees they meet safety standards.​

4. Don’t Skimp on Space​

Leave extra room for wire bends and pulls. A body that's too small will make threading wires frustrating and could lead to damaged insulation.​

Final Thoughts​

Conduit bodies might seem like small parts, but they're critical to a smooth, safe, and compliant electrical system. Whether you're reaching for an LB body for a residential corner turn or a stainless steel T body for a food plant, taking the time to choose the right material, size, and style will save you from rework later.​
